SKU 158505

Overview:

To take advantage of the additional travel that the RXT Rear Suspension System offers, ICON engineers had to scrap the OE leaf springs and develop a replacement that addressed issues found in the R&D process. The result is a user-adjustable multi-rate leaf pack that offers a major performance gain for almost every Tacoma setup imaginable. Features like tip inserts and leaf separators reduce friction and increase ride comfort, while a military wrapped front eyelet improves the durability and strength of the leaf spring. To increase the ride quality of the truck and gain additional droop travel, the spring rate has been lowered slightly. While many Tacoma owners will embrace this, there are those who have outfitted their trucks with a significant amount of weight in the form of a bed rack, roof top tent, spare tires and parts or other additions. Understanding this, the leaf pack was designed with an additional leaf (included with kit) that can be exchanged or added to the pack yielding an additional 10% or 20% spring rate that will handle more "outfitted" vehicles.

Features & Benefits:

3 user-adjustable spring rates for unique vehicle configurations
Military wrap front eyelet for increased durability
Galvanized leaf separators reduce friction and aid in corrosion resistance
Leaf tip inserts reduce noise and increase ride comfort
Potential for increased wheel travel (when used with RXT shock) without sacrificing up-travel
"ICON 1K" tested under rigorous off-road conditions to validate tune, performance, strength, and durability
Direct bolt-in to OEM spring location makes for an easy install

Lift Options:

Option 1 -Lift height over stock: 1.875'' (unloaded)

Option 2 -Lift height over stock: 2.25'' (unloaded) | 1.75'' (200lb load)

Option 3 -Lift height over stock: 2.625'' (unloaded) | 1.125'' (600lb load)

Tech Info:

For best results (and increased wheel travel), use in conjunction with ICON RXT rear shocks.

Kit Includes:

Leaf Springs (2)
Leaf Spring Bushings (2)

Leaf Springs do not include u-bolts, but they can be purchased here: u-bolts. It is not recommended to reuse existing u-bolts.
